TI 24 Indoor Termination for 24 kV Cables
Key Features
Technical Excellence
Scope of Delivery
Applications
Engineered for Excellence in High-Voltage Cable Termination
The TI 24 Indoor Termination is a state-of-the-art solution designed for the reliable and efficient termination of 24 kV cables in indoor environments. Built with precision and durability in mind, this termination system combines advanced materials, innovative engineering, and user-friendly features to meet the demanding requirements of modern electrical installations.
- Quick and Easy InstallationThe TI 24 features a one-piece, pre-molded design made from high-quality silicone rubber. This not only simplifies the installation process but also minimizes the risk of installation errors, making it ideal for both new installations and system upgrades.
- Integrated Stress ControlEquipped with a capacitive stress control system, the TI 24 ensures optimal electrical field distribution, significantly enhancing the termination’s performance and extending its service life.
- Versatile Connection CompatibilityDesigned to accommodate a wide range of cable lug types—including screw type, hexagonal pressing, and deep indent pressing—this termination offers unmatched flexibility for various installation scenarios.
- Compact and Efficient DesignThe termination’s short body and optimized shed arrangement provide a long creepage distance, ensuring excellent insulation performance even in compact switchgear environments.
- Voltage EnduranceRated for up to 24 kV, the TI 24 is built to withstand high-voltage conditions with ease. It meets rigorous standards such as IEC 60840, ensuring dependable operation in critical applications.
- Robust Electrical PerformanceThe termination is tested for:
- AC withstand voltage: 90 kV (30 minutes)
- Impulse withstand voltage: 325 kV
- Partial discharge: < 5 pC at 54 kV
- Heating cycles and long-term reliability
- Short-Circuit ResistanceEngineered to handle:
- Thermal short-circuit currents up to 18.5 kA
- Dynamic short-circuit currents up to 45 kA
- Material and ConstructionMade from geometrically pre-molded silicone rubber using injection molding, the TI 24 offers superior mechanical strength and environmental resistance.
Each TI 24 termination kit includes:
- Silicone Rubber Termination Body
- Conductor Cable Lugs (for secure electrical connections)
- Earthing Cable Lugs (for enhanced grounding)
- Assembly Instructions (clear, step-by-step guidance)
- All Required Accessories for a complete and seamless installation
Ideal for indoor electrical installations where high reliability and performance are essential, the TI 24 is suitable for:
- Power distribution systems
- Industrial switchgear
- Utility substations
- Infrastructure upgrades
Whether you're working on a new build or retrofitting an existing system, the TI 24 offers the durability, flexibility, and ease of use that professionals demand.
