Connectors

CSS-A 12-24 kV, 250 A

Straight connector made of EPDM for XLPE and EPR-insulated 1- or 3-core cables with Al or Cu conductors for 12–24 kV. For in and outdoor applications. Fits outercone bushings type A (250 A) according to EN 50181.
Straight connector made of EPDM for XLPE and EPR-insulated 1- or 3-core cables with Al or Cu conductors for 12–24 kV. For in and outdoor applications. Fits outercone bushings type A (250 A) according to EN 50181.

Product Information

Further product data, downloads and certificates

Product Information
Downloads

Product Information

Max. cross section: 95 mm²
Core insulations: 10 - 25.5 mm
Core type: Single-Core, Three-Core
Max. operating Voltage (Ur): 24 kV
Product type: Straight Connector
Application: Outdoor Termination, Indoor Termination
DIN norms: EN 50181., HD 629.1 S2
Max. cross section: 95 mm²
Core insulations: 10 - 25.5 mm
Core type: Single-Core, Three-Core
Max. operating Voltage (Ur): 24 kV
Product type: Straight Connector
Application: Outdoor Termination, Indoor Termination
DIN norms: EN 50181., HD 629.1 S2

Downloads

CSE-​A 250, CSS-​A 250

CSE-​A 250, CSS-​A 250
