Telecom energy cables

S1Z1Z1

Flexible and easy to prepare for connection to simplify installation and reduce cost on site. Double jacket insulation. Halogen free, flame retardant, flexible and double insulated single conductor cable for connection of back-up batteries, central office power distribution or grounding. CPR class B2ca and UL listed. Indoor and outdoor use.
Flexible and easy to prepare for connection to simplify installation and reduce cost on site. Double jacket insulation. Halogen free, flame retardant, flexible and double insulated single conductor cable for connection of back-up batteries, central office power distribution or grounding. CPR class B2ca and UL listed. Indoor and outdoor use.

Product Information

Further product data, downloads and certificates

Product Information
Downloads

Product Information

Material conductor: Copper
Conductor size: 25; 35; 50; 70; 95; 150; 240
Material outer sheath: PE
Number of cores: 1
Core type: Single core
Bending radius: 6 x OD
Screen: No
Sunlight resistant: Yes
Rated voltage (U0/U): 600/600 V
Max. operating Temperature: +90°C
Min. operating Temperature: -20°C
CPR fire class: B2ca
Standard / Norm: UL listed
Material conductor: Copper
Conductor size: 25; 35; 50; 70; 95; 150; 240
Material outer sheath: PE
Number of cores: 1
Core type: Single core
Bending radius: 6 x OD
Screen: No
Sunlight resistant: Yes
Rated voltage (U0/U): 600/600 V
Max. operating Temperature: +90°C
Min. operating Temperature: -20°C
CPR fire class: B2ca
Standard / Norm: UL listed
